2603 Cylindrical Retaining Anaerobic Adhesive
2603
Overview
2603 Cylindrical Retaining Anaerobic Adhesive
is a high-strength, low-viscosity green adhesive designed for press-fit or radial gap retention of up to 0.1 mm in shaft-hole assemblies. With excellent oil tolerance for use on lightly oiled surfaces, it employs anaerobic curing technology to deliver superior retention strength and durability. Ideal for mechanical manufacturing, automotive, and industrial assembly, it meets demands for efficiency and high reliability.
Features
- Color: Green
- Viscosity: 100 ~ 150 MPa·s
- Density: 1.1 g/cm³
- Maximum Gap Fill: 0.1 mm
- Shear Strength: ≥20 MPa
- Initial Cure Time at Room Temperature: ≤30 minutes (hardness)
- Full Cure Time at Room Temperature: 24 hours
- Operating
| Product Code | Color | Viscosity MPa·s |
Density g/cm³ |
Max Gap Fill mm |
Shear Strength MPa |
Room Temp Cure Time Fixture (min) |
Room Temp Cure Time Full Cure (h) |
Operating Temperature °C |
|---|---|---|---|---|---|---|---|---|
| 2603 | Green | 100–150 | 1.1 | 0.1 | ≥20 | ≤30 | 24 | -50–150 |
| 2620 | Green | 5000–11000 | 1.16 | 0.25 | ≥17.2 | ≤60 | 24 | -50–200 |
| 2638 | Green | 2000–3000 | 1.1 | 0.25 | ≥25 | ≤10 | 24 | -50–150 |
| 2648 | Green | 450–550 | 1.1 | 0.15 | ≥25 | ≤10 | 24 | -50–150 |
| 2661 | Clear Yellow to Dark Amber | 400–600 | 1.13 | NA | ≥15 | ≤14 | 24 | -50–150 |
| 2662 | Red | 1.05 | NA | ≥10 | ≤30 | 24 | -50–150 | |
| 2680 | Green | 1000–1750 | 1.1 | 0.25 | ≥20 | ≤10 | 24 | -50–150 |
